Motor type arrester - Wenzhou mingneng Electrical co.,ltd

MOA type	Sys R.V	MOA R.V	MCOV	D.C.U1mA	1/10μs Steep current impulse	8/20μs Lighting current impulse	30/60μs Switching current impulse	2ms Rectangular current impulse(2ms)	4/10μs High curerent impulse	Fig No
MOA type	kV(r.m.s)			≮kV	≯kV			A	kA	Fig No
HY5WD-4/9.5
HY5WD-4/9.5	3.15	4.0	3.2	5.7	10.7	9.5	7.6	400	65
HY5WD-8/18.7	6.3	8.0	6.3	11.3	21	18.7	15.0	400	65
HY5WD-13.5/31	10.5	13.5	10.5	18.9	34.7	31.0	25.0	400	65
HY5WD-17.5/40	13.8	17.5	13.8	24.8	44.8	40.0	32.0	400	65
HY5WD-20/45	15.8	20	15.8	28.4	50.4	45.0	36.0	400	65
HY5WD-23/51	18.0	23	18.0	32.0	57.2	51.0	40.8	400	65
HY2.5WD-4/9.5	3.15	4.0	3.2	5.7	10.7	9.5	7.6	200	65
HY2.5WD-8/18.7	6.3	88	6.3	11.3	21.0	18.7	15.0	200	65
HY2.5WD-13.5/31	10.5	13.5	10.5	18.9	34.7	31.0	25.0	200	65
HY1.5WD-2.4/6	3.15	2.4	1.9	3.4		6.0		200	65
HY1.5WD-5/12	6.3	5.0	3.8	7.1		12.0		200	65
HY1.5D-8/19	10.5	8.0	6.4	11.3		19.0		200	65
注:1、“HY5-”为发电机用；2、“HY2.5-”为电动机用；“HY1.5-”为电机中性点用。
