Polymeric hoursed metal-oxide surge arrester without gaps (export) 5kA series

MOA Type	MOA Rated	MCOV	1/10μs Steep current　impulse	8/20μs Lightning current impulse	30/60μs Switching current impulse	2ms Rectangular current impulse withstand	4/10us High current impulse withstand
MOA Type	kV(r.m.s)		≮kV			A	kA
HY5W-3	3	2.55	11.3	9	8.9	150	65
HY5W-6	6	5.10	22.6	18	16.8	150	65
HY5W-9	9	7.65	33.7	27	23.8	150	65
HY5W-10	10	8.4	36	30	26.4	150	65
HY5W-11	11	9.4	40	33	30	150	65
HY5W-12	12	10.2	42.2	36	31.7	150	65
HY5W-15	15	10.7	51	45	38.5	150	65
HY5W-18	18	15.3	61.5	54	46.5	150	65
HY5W-21	21	17.0	71.8	63	54.5	150	65
HY5W-24	24	19.5	82	72	62.6	150	65
HY5W-27	27	22.0	92	81	69.8	150	65
HY5W-30	30	24.4	102	90	79	150	65
HY5W-33	33	27.5	112	99	86.7	150	65
HY5W-36	36	29.0	123	108	92.4	150	65
HY5W-39	39	31.5	117	103	94	150	65
HY5W-42	42	33.6	126	111	101	150	65
HY5W-45	45	36.5	128	119	105	150	65
HY5W-48	48	39.0	139	127	110	150	65
HY5W-51	51	40.8	151	134	115	150	65
HY5W-54	54	42.0	160	143	119	150	65
HY5W-60	60	48.0	178	159	132	150	65
HY5W-66	66	52.8	196	175	145	150	65
HY5W-69	69	55.2	205	183	152	150	65
